VT UltraMic-384 - Audio and Ultrasonic Analyzer

PC USB 16-bit single-channel 384kSPS 20Hz~190kHz audio and ultrasonic analyzer                             Manual US$699.95     Free Express Shipping Download and try the fully functional Multi-Instrument software using your sound card as the ADC and DAC device! 1. Instroduction VT UltraMic-384 is a 16-bit, single-channel, audio and ultrasonic USB microphone specially designed for sound measurement in the frequency range from 20Hz to up to 190kHz. When used in conjunction with the Multi-Instrument® software, it converts any desktop, laptop, or tablet PC into a powerful audio and ultrasonic sound analyzer. 2. Package Contents 1) VT UltraMic-384 USB microphone with an integrated 1.1 m USB cable 2) USB hardkey (contains a Multi-Instrument Pro software license) 3) Microphone clip and stand 4) CD (contains the copy-protected Multi-Instrument Software) 5) Carrying case   3. VT UltraMic-384 Hardware Specifications Sampling Frequency 384 kHz (original) Frequency Range 20 Hz ~ 190 kHz ADC Bit Resolution 16 Bits Number of Input Channels 1 Frequency Accuracy 0.01% Full-Scale Sound Level (at 1kHz) 100 dB (Typical), when Switch 1 = On, Switch 2 = Off, (Default Setting) 80 dB (Typical), when Switch 1= Off, Switch 2 = On 120 dB (Typical), when Switch 1= Off, Switch 2 = Off Anti-aliasing Filter 190 kHz at Sampling Rate 384 kHz, proportionally adaptive to Sampling Rate Chosen Buffer Size Virtually unlimited (streaming mode) Digital Input / Output Standard USB Audio Class 1.1 PC Interface USB 2.0 Full Speed / USB 1.1 Device Category in Multi-Instrument ADC Device Sound Card MME DAC Device Not Applicable Power Bus powered by USB port, no external power source required Power Consumption Max. 0.7W Dimensions Φ25.4×160 mm, aluminum case Dimensions 0° C ~50° C 4. Examples (1) Detection of Ultrasound Burst (about 40 kHz ) Emitted by Car Parking Sensor
